Intake Manifold

Intake manifold retaining bolts 12 Nm (105 in. lbs.)

CAUTION: Proper torque of the throttle body is critical to normal operation. If the throttle body is over-torqued, damage to the throttle body can occur resulting in throttle plate malfunction.

Throttle body mounting bolts 7 Nm (60 in. lbs.)
