Battery Retainer - Installation

INSTALLATION

1. Install the battery hold down (2) into the vehicle.
2. Install the battery hold down retaining bolt (1). Tighten the bolt to 7 Nm (62 in. lbs.).

3. Install the air cleaner fresh air duct (2) and secure in place by rotating the two retaining clips (3).
4. Connect the battery negative cable.
