DTC B00C0-93; B00C1-93: Occupant Classification Sensor Communication Error: Notes
WARNING: This page is about a different car, the 2016 Mazda MX-5 Miata. However, it is still accessible from the selected car via links, so may be relevant.
| System malfunction location |
- B00C0:93:Occupant classification sensor communication error (occupant classification sennsor mat structural malfunction)
- B00C1:93:Occupant classification sensor communication error (occupant classification sennsor shield mat structural malfunction)
|
| Detection condition |
WARNING:
- Detection conditions are for understanding the DTC outline before performing an inspection. Performing an inspection according to only the detection conditions may cause injury due to an operating error, or damage the system. When performing an inspection, always follow the inspection procedure.
- Malfunction signal receibed occupant sensor
|
| Fail-safe |
- |
| Possible cause |
- Occupant classification sensor malfunction
- SAS control module malfunction
|
|
|
