Removal And Installation: Notes

WARNING:
  • Before removal of the air bag module, refer to AIR BAG RESTRAINT SYSTEMS .
  • When removing and installing the steering wheel, do not let it bump against the air bag module.
Fig 1: Removing/Installing Steering Wheel
G01888460Courtesy of MITSUBISHI MOTOR SALES OF AMERICA.
