Exploded View
|
1. |
Drain plug |
2. |
Cylinder block |
3. |
Oil jet |
|
4. |
Piston rings |
5. |
Piston |
6. |
Circlip |
|
7. |
Connecting rod |
8. |
Thrust bearing |
9. |
Connecting rod bearing |
|
10. |
Crankshaft key |
11. |
Crankshaft |
12. |
Main bearings |
|
13. |
Flywheel (M/T models) |
14. |
Signal plate |
15. |
Rear oil seal |
|
16. |
Pilot converter (CVT models) |
17. |
Drive plate (CVT models) |
18. |
Drive plate reinforcement (CVT models) |
|
19. |
Engine oil temperature sensor |
20. |
Engine oil pressure sensor |
21. |
Knock sensor |
|
A. |
Refer to Disassembly and Assembly . |
B. |
Main bearing cap |
CAUTION:
- Main bearing cap cannot be replaced individually, it is machined with the cylinder block and must be serviced as an assembly.
- Connecting rod cap cannot be replaced individually, it is machined with the connecting rod and must be serviced as an assembly.
- Main bearing (upper) and main bearing (lower) are serviced together.
- Connecting rod bearing (upper) and connecting rod bearing (lower) are serviced together.
