Removal Procedure

WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
  1. Adjust the seat to full forward.
    2. Fig 1: Front Seat Back Panel
    GM1246652Courtesy of GENERAL MOTORS CORP.
  2. Fold the seat flat.
  3. Remove the screws from the seat back panel.
  4. Remove the seat back panel.
