Installation Procedure

WARNING: This page is about a different car, the 2002 Pontiac Grand Prix. However, it is still accessible from the selected car via links, so may be relevant.
  1. Install the bulb to the ashtray lamp socket.
  2. Install the socket to the lamp housing. Rotate the lamp counterclockwise to secure.
  3. Install the ashtray to the I/P. Refer to ASHTRAY REPLACEMENT .
    Fig 1: Ashtray Lamp & Bulb
    G01616101Courtesy of GENERAL MOTORS CORP.
