Tire Placard
WARNING: This page is about a different car, the 2003 Saturn Vue. However, it is still accessible from the selected car via links, so may be relevant.
| Callout | Component Name |
|---|---|
| 1 | Specified Occupant Seating Positions |
| 2 | Total Occupant Seating |
| 3 | Maximum Vehicle Capacity Weight |
| 4 | Tire Pressures, Front, Rear, and Spare |
| 5 | Tire Speed Rating, Front, Rear, and Spare |
| 6 | Tire Label Code |
| 7 | Engineering Model Minus First Character |
| 8 | Tire Sizes, Front, Rear, and Spare |
| 9 | Vehicle Identification Number |
The Tire Placard label is located on the left hand front door. Refer to the placard in order to obtain the following information:
- The maximum vehicle capacity weight
- The cold tire inflation pressures
- The tire sizes original equipment tires
- The tire speed ratings original equipment tires
