Component Inspection

  1. CHECK INPUT SPEED SENSOR-I
    1. Turn ignition switch OFF.
    2. Disconnect input speed sensor harness connector.
    3. Remove the sensor. Refer to INPUT SPEED SENSOR : Exploded View .
    4. Visually check the sensor for chipping.
      GNSJMBIA2060Z-060Courtesy of NISSAN NORTH AMERICA, INC.

    Is the inspection result normal?

    YES

    GO TO 2.

    NO

    Replace input speed sensor.

  2. CHECK INPUT SPEED SENSOR-II

    Check resistance between input speed sensor terminals as per the following items.

    Terminals (Polarity)

    Resistance

    1 (+) - 2 (-)

    Except 0 or ∞ Ohm [at 25 deg. C (77 deg. F)]

    1 (+) - 3 (-)

    2 (+) - 3 (-)

    Is the inspection result normal?

    YES

    INSPECTION END

    NO

    Replace input speed sensor.
